Standard Technical Parameters

Valve body
Nominal diameter: DN50-DN600
Body material: WCB, 304, 316
Connection: Wafer, lug wafer
Pressure class: 150LB, 300LB
Structure: Double eccentric

Design and manufacturing standards:
Design and manufacture: API609
Connection standard: ANSI B 16.5
Structure length: ANSI B 16.10 GB12221
Pressure testing: API598

Valve components
Seat sealing: PTFE: -30~180℃
Alloy steel: -30~425℃
Disc material: WCB, 304, 316
Stem material: 17-4PH
Applicable medium: Chlorine, oxygen, high vacuum and corrosive
medium, use of high frequency.
