Features

1. Product design is in accordance with NB/T47044-2014 and ASME B16.34-2013 standards:
2. The valve stem has been tempered and nitrided, and has high temperature resistance, wear resistance and good corrosion resistance.
3. Anti-scouring valve seat, valve disc and anti-scouring sleeve are all nitrided and have scouring resistance. They are replaceable accessories.
4. The medium flow direction adopts high inlet and low outlet, which has the characteristics of small opening and closing torque and easy opening.
5. The valve seat and valve disc sealing surface are made of cobalt-based hard alloy surfacing or plasma spray welding, which has good high temperature resistance, wear resistance and abrasion resistance.
6. The valve body adopts forging structure.

Product standards

1. Design standards: in accordance with DL/T531-1994, JB/T3595-2002, NB/T 47044-2014.

2. Design standards: ASME B16.34-2013.

Nominal pressure: PN160-PN630 (900LB-3500LB), P100V P140VP170V-

P7100V-PAT140V-PS7170V

Nominal diameter: DN10-DN100 (2′-4′)

Main material: 1, 25#, 12Cr1MoV

2、ASTM A105、ASTM A182 F11. ASTM A182 F22. ASTM A182 F91、ASTM A182 F92

Operating temperature:

1、WCB-29°C~425°C

2. Alloy steel: -29°C-540°C. -29°C~570°C

3. F91: -29°C~610°C

Applicable medium: water, steam, etc.

Connection method: welding

Transmission mode: manual, gear drive, electric, pneumatic, hydraulic
