Standard Technical Parameters

Valve body
Nominal diameter: DN10-DN100
Body material: 304, 316,316L
Connection: Thread
Pressure class: PN1.6-PN6.3MPa
Structure: Float ball core

Design and manufacturing standards
Thread type: G, NPT, BSPT, BSP, DIN259/2999
Top flange: ISO5211
Pressure testing: ISO5208 API598

Valve components
Seat sealing: PTFE: -30~180℃, PPL: -30~250℃
Core material: 304, 316, 316L
Stem material: 304
Applicable medium: Water, liquid, gas, oil, acid, alkali corrosive medium.
Note: Valve body, disc, seat material characteristics please as shown in
table P116
